e-KOLO CF-Koloride

Carbon E-Gravel

Our first electric gravel bike, equipped with a power assist system from MAHLE—a leader in the production of the lightest electric motors on the market. Impressive range, which can be extended with an additional battery. Simple design, discreet electrical system, lightness, speed, and efficiency—these are the undeniable strengths of this electric gravel bike. Maximum comfort while riding in the city or on longer off-road trips.

e-KOLO CF-Koloride

e-KOLO CF-Koloride

Gallery

Properties

  • Frame: Made of carbon. The geometry was developed at Koloride to ensure performance on any route.
  • Engine: The latest MAHLE X20 dynamic motor with 250 W of power
  • Battery: The high-performance Mahle iX2+ battery, with a capacity of 242 Wh, provides a range of up to 80–100 km
  • Fork: all-carbon, tapered
  • Internal routing: Internal cable routing
  • Support: Pressfit 86.5
  • Tire clearance: 700 x 45C
  • Weight: frame approx. 1190 g (size M); fork approx. 430 g
  • Weight of the bicycle: Starting at 11 kg!

Frame Geometry

Frame Geometry

XS

161-166

S

165-172

M

171-177

L

177-184

XL

184-190

Geometry Details

Seat tube length (K)
XS
448,7
S
468
M
482
L
501
XL
517
Length of the top tube (E)
XS
499,4
S
519,6
M
534,4
L
550,4
XL
563,7
Frame head height in mm (H)
XS
115
S
135
M
147
L
159
XL
178
Head angle (J)
XS
70°
S
70°
M
70,5°
L
71°
XL
71°
Seat angle (I)
XS
75°
S
74,5°
M
74°
L
73,5°
XL
73,5°
Length of chain tubes in mm (C)
XS
430
S
430
M
430
L
430
XL
430
Wheelbase in mm (D)
XS
1001,7
S
1018,6
M
1024,3
L
1025,5
XL
1039,3
Stack in mm (F)
XS
535
S
554
M
567
L
582
XL
600
Reach in mm (G)
XS
356
S
366
M
372
L
378
XL
386
Support offset in mm
XS
72
S
72
M
72
L
72
XL
72

Specification

Wheels

  • Wheels: built by the Polish manufacturer Lemonbike.eu on DT SWISS G540 rims with DT SWISS 350 Straightpull Centerlock hubs + Sapim RACE spokes

Tires

  • Tire: Pirelli Cinturato Gravel RC-X. Size 45-622 (700 x 45C)

Fork

  • Fork: Rigid, full-carbon with mounting holes, tapered steerer tube.

Saddle

  • Saddle: Fizik Terra Argo X5

Steering wheel

  • Steering wheel: Zipp Service Course XPRL 70, made of lightweight aluminum alloy with a 10-degree dropout angle, width 400/420/440 mm
  • Handlebar tape: Zipp Service Course
  • Bridge: Token length: 80/90/100/110 mm

Powertrain

  • Door handle levers: SRAM APEX D1
  • Rear derailleur: SRAM APEX XPLR D1 MAX 44T
  • Crank: SRAM APEX D1 DUB WIDE 40T
  • Caste: SRAM PG 1231 D1 XPLR 11-44
  • Chain: Apex D1 Flattop with PowerLock clip, 12 rows
  • Support: Pressfit 86.5
  • Brakes: SRAM APEX
  • Brake discs: SRAM Rotor

Configuration is for reference only. Full customization available.

Go to Configurator
